H3CR

  • CAD Library
  • H3CR Solid-state Timer Datasheet
  • Thank you for downloading the H3CR Solid-state Timer Datasheet

    Download again

    Did you know that 4 out of 5 distributors buy this product in a bundle?

    There are many variations of passages of Lorem Ipsum available, but the majority have suffered alteration in some form, by injected humour, or randomised words which don't look even slightly believable.

    Read more
Features

DIN 48 x 48mm multi-functional timer series

This elaborate range of solid state timers provides you with a multi-functional timer, twin timer, star-delta timer and a power OFF-delay timer.

  • 48 x 48mm front-panel/plug-in
  • High-/low-voltage models (except -H and -G)
  • 0.05 s to 300 h (except -H and -G)
  • DPDT, 5A at 250VAC
  • Transistor 100mA at 30VDC
Specifications & ordering info
Product Type Installation type Functions Size Terminal Operating mode Output type Contact description Time range Supply voltage AC Supply voltage DC Number of pin contact Inputs Features
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.1 s - 600 h 100-240 V 100-125 V 11 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.1 s - 600 h 24-48 V 12-48 V 11 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay DPDT 0.1 s - 600 h 100-240 V 100-100 V 8 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay DPDT 0.1 s - 600 h 24-48 V 12-48 V 8 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 8 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 8 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay SPDT 0.05 s - 300 h 100-240 V 100-125 V 8 No-voltage Instantaneous contact
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Relay SPDT 0.05 s - 300 h 24-48 V 24-48 V 8 No-voltage Instantaneous contact
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start), Interval (Power ON Start), ON Delay (Power ON Start), One-shot Output (Power ON Start) Transistor 0.05 s - 300 h 24-48 V 12-48 V 8 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 11 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 11 No-voltage
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 11 AC voltage, DC voltage, Signal (NPN/PNP)
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 11 AC voltage, DC voltage, Signal (NPN/PNP)
Analog Socket Multi-functional 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Signal Start), Signal ON/OFF Delay Transistor 0.05 s - 300 h 24-48 V 12-48 V 11 No-voltage
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Power ON Start) Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 8
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Power ON Start) Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 8
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start) Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 8
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start) Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 8
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Power ON Start) Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 11
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker OFF Start (Power ON Start) Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 11
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start) Relay DPDT 0.05 s - 300 h 100-240 V 100-125 V 11
Analog Socket Twin 1/16 DIN (48 x 48 mm) Plug-in Flicker ON Start (Power ON Start) Relay DPDT 0.05 s - 300 h 24-48 V 12-48 V 11
Analog Socket Star-delta 1/16 DIN (48 x 48 mm) Plug-in Star-delta Relay 3 x SPST-NO 0.5 s - 120 s 100-120 V 0-0 V 8 Instantaneous contact
Analog Socket Star-delta 1/16 DIN (48 x 48 mm) Plug-in Star-delta Relay 3 x SPST-NO 0.5 s - 120 s 200-240 V 0-0 V 8 Instantaneous contact
Analog Socket Star-delta 1/16 DIN (48 x 48 mm) Plug-in Star-delta Relay 2 x SPST-NO 0.5 s - 120 s 200-240 V 0-0 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 min 100-120 V 0-0 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 min 200-240 V 0-0 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 s 200-240 V 0-0 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 min 24-24 V 24-24 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 s 24-24 V 24-24 V 8
Analog Socket Power OFF-delay 1/16 DIN (48 x 48 mm) Plug-in OFF Delay (Power) Relay DPDT 0.05 s - 12 min 200-240 V 0-0 V 11
